Lexus NX: Maintenance data (fuel, oil level, etc.)

Lexus NX Owners Manual / Vehicle specifications / Specifications / Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Lexus NX. Maintenance data (fuel, oil level, etc.)

*1: Unladen vehicle
*2: Vehicles with towing package

Vehicle identification

■ Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in registering the ownership of your vehicle.

This number is stamped on the top left of the instrument panel.

Lexus NX. Maintenance data (fuel, oil level, etc.)

This number is also on the Certification Label.

Lexus NX. Maintenance data (fuel, oil level, etc.)

This number is also stamped under the right-hand front seat.

Lexus NX. Maintenance data (fuel, oil level, etc.)

■ Engine number The engine number is stamped on the engine block as shown.

Lexus NX. Maintenance data (fuel, oil level, etc.)

Engine

Lexus NX. Maintenance data (fuel, oil level, etc.)

Fuel

Lexus NX. Maintenance data (fuel, oil level, etc.)

Electric motor (traction motor)

Front

Lexus NX. Maintenance data (fuel, oil level, etc.)

Rear

Lexus NX. Maintenance data (fuel, oil level, etc.)

Hybrid battery (traction battery)

Lexus NX. Maintenance data (fuel, oil level, etc.)

Lubrication system

■ Oil capacity (Drain and refill [Reference*])

Lexus NX. Maintenance data (fuel, oil level, etc.)

*: The engine oil capacity is a reference quantity to be used when changing the engine oil.

Warm up the engine and turn off the hybrid system, wait more than 5 minutes, and check the oil level on the dipstick.

■ Engine oil selection "Toyota Genuine Motor Oil" is used in your Lexus vehicle. Use Lexus approved "Toyota Genuine Motor Oil" or equivalent to satisfy the following grade and viscosity.

Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it must be replaced with SAE 0W-20 at the next oil change.

Lexus NX. Maintenance data (fuel, oil level, etc.)

  1. Outside temperature

Oil viscosity (0W-20 is explained here as an example):

How to read oil container label: The International Lubricant Specification Advisory Committee (ILSAC) Certification Mark is added to some oil containers to help you select the oil you should use.

Lexus NX. Maintenance data (fuel, oil level, etc.)

Cooling system

Lexus NX. Maintenance data (fuel, oil level, etc.)

*: The coolant capacity is the quantity of reference.

If replacement is necessary, contact your Lexus dealer.

Ignition system

■ Spark plug

Lexus NX. Maintenance data (fuel, oil level, etc.)

NOTICE

■Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system

■ 12-volt battery

Lexus NX. Maintenance data (fuel, oil level, etc.)

■ Charging rates

Lexus NX. Maintenance data (fuel, oil level, etc.)

Hybrid transmission

Lexus NX. Maintenance data (fuel, oil level, etc.)

*: The fluid capacity is the quantity of reference.

If replacement is necessary, contact your Lexus dealer.

NOTICE

■Transmission fluid type Using transmission fluid other than "Toyota Genuine ATF WS" may ultimately damage the hybrid transmission of your vehicle.

Rear differential (Rear electric motor)

Lexus NX. Maintenance data (fuel, oil level, etc.)

*: The fluid capacity is the quantity of reference.

If replacement is necessary, contact your Lexus dealer.

NOTICE

■Transmission fluid type Using transmission fluid other than "Toyota Genuine ATF WS" may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.

Brakes

Lexus NX. Maintenance data (fuel, oil level, etc.)

*: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50.0 kgf) while the hybrid system is operating.

Steering

Lexus NX. Maintenance data (fuel, oil level, etc.)

Tires and wheels

Type A

Lexus NX. Maintenance data (fuel, oil level, etc.)

Type B

Lexus NX. Maintenance data (fuel, oil level, etc.)

Compact spare tire

Lexus NX. Maintenance data (fuel, oil level, etc.)

Light bulbs

  1. Wedge base bulbs (clear)
  2. Wedge base bulbs (amber)

*: If equipped

Lexus NX. Maintenance data (fuel, oil level, etc.)

  1. Wedge base bulbs (clear)
  2. Wedge base bulbs (amber)

*: If equipped
